MODEL INDENTIFICATION:
JKP -W - 20 - SK - 1/6 - 5 - V - F
1 2 3 4 5 6 7 8
| 1 | MODEL | JKP |
| 2 | BASE SHAPE | W-Groove extemal Square/Standard Type |
| 2 | IN/OUTLET | 20-32*20, 25-40*25; 40-50*40 |
| 3 | SPECIFIC GRAVITY | SK-1.1 SP-1.4 |
| 4 | POWER | 1/8HP,1/6HP,1/4HP,1/3HP,1/2HP,3/4HP,1HP,2HP,3HP |
| 5 | FREQUENCY | 5-50HZ, 6-60HZ |
| 6 | O-RING | E-EPDM V-VITON |
| 7 | MATERIAL | F-FRPP P-PVDF |
| 8 | SHAFT MATERIAL | 4-SUS304 6-SUS316 Ti-Ti |
| 9 | VOLTAGE | 2-220V 3-380V 4-415V |
| MODEL | SG | IN/OUT | POWER | PHASE | 50HZ | 60HZ | WEIGHT(kg) | ||
| HEAD(m) | FLOW(L/min) | HEAD(m) | FLOW(L/min) | ||||||
| JKP-20SK-1/8 | 1:1 | 32*20 | 1/8 | 1 | 3.9 | 33 | 4.9 | 50 | 4.9 |
| JKP-20SK-1/6 | 1:1 | 32*20 | 1/6 | 1 | 4.5 | 40 | 5.2 | 60 | 4.9 |
| JKP-25SK-1/4 | 1:1 | 40*25 | 1/4 | 3 | 6 | 69 | 7.9 | 75 | 7.8 |
| JKP-25SK-1/3 | 1.1 | 40*25 | 1/3 | 3 | 7 | 78 | 9.8 | 100 | 9 |
| JKP-25SK-1/2 | 1:1 | 40*25 | 1/2 | 3 | 13.4 | 170 | 13.6 | 163 | 9 |
| JKP-40SK-1 | 1:1 | 50*40 | 1 | 3 | 12.5 | 280 | 15 | 350 | 17.6 |
| JKP-40SK-2 | 1:1 | 50*40 | 2 | 3 | 13.8 | 320 | 19 | 350 | 20.5 |
| JKP-40SK-3 | 1:1 | 50*40 | 3 | 3 | 23.5 | 450 | 25 | 450 | 23 |
PRODUCT FEATURES:
1. JKP series vertical pumps are manufactured from higher grade raw material and can be define to FRPP,PVDF for customer selection；
2. The vertical pump JKP series are designed to tun installed in the tank or process module,expect 1/8hp,1/6hp,all the test model have a slotted air gap in the pump base and a dry vapor seal ,there by preventing chemical penetrating to the motor bearing;
3. It is designed to inside tank and can be fitted together with filter system;the pump are used in a wide range of applications from chemical recirculation to process modules;
4. The weight of the pump is lighter,leak free operation and easy maintenance;
5. Vertical pumps can run dry without damage to vapor seal;
6.Max Operating Temperature: FRPP 75℃; PVDF:100;
7.For corrosive environment, it is recommended to use Titanium bolt and nuts and Epoxy paint on motor body to prolong motor lifespan;
8.JK has been certified with ISO9001:2005,CE certification,Production&sales intellectual property management system certification;
9.1 year warranty;
