MODEL INDENTIFICATION:
JKH - W - 40 - SK - 5 - 5 - V - F - Ti
1 2 3 4 5 6 7 8 9
| 1 | MODEL | JKH |
| 2 | BASE SHAPE | F-Square Y-Circle W-Groove Extemal Standard Type / Special Customized |
| 3 | IN/OUTLET(mm) | 32-50*32 40-50*40 50-65*50 |
| 4 | SPECIFIC GRAVITY | SK-1.1 SP-1.4 |
| 5 | POWER | 1-1HP, 2-2HP, 3-3HP, 5-5HP, 7.5-7.7HP, 10-10HP |
| 6 | FREQUENCY | 5-50HZ 6-60HZ |
| 7 | O-RING | E-EPDM V-VITON |
| 8 | MATERIAL | F-FRPP P-PVDF |
| 9 | SHAFT MATERIAL | 4-SUS304 6-SUS316 Ti-Ti |
| MODEL | SPEC | SG | IN/OUT | POWER | POLE | 50HZ | 60HZ | WEIGHT(kg) | ||
| HEAD(m) | FLOW(L/min) | HEAD(m) | FLOW(L/min) | |||||||
| JKH-W | 32SK-1 | 1:1 | 50*32 | 1 | 2 | 18 | 200 | 17 | 160 | 17 |
| JKH-W | 40SK-1 | 1:1 | 50*40 | 1 | 2 | 18 | 210 | 16.5 | 170 | 19.2 |
| JKH-W | 32SK-2 | 1:1 | 50*40 | 2 | 2 | 26 | 290 | 25 | 260 | 20.5 |
| JKH-W | 40SK-2 | 1:1 | 50*40 | 2 | 2 | 26 | 380 | 24 | 300 | 21.6 |
| JKH-W | 40SK-3 | 1:1 | 50*40 | 3 | 2 | 28 | 400 | 27 | 350 | 24.6 |
| JKH-W | 50SK-5 | 1:1 | 50*50 | 5 | 2 | 32 | 560 | 30 | 520 | 35.7 |
| JKH-W | 50SK-7.5 | 1:1 | 50*50 | 7.5 | 2 | 44 | 640 | 38 | 620 | 55.8 |
| JKH-W | 50SK-10 | 1:1 | 50*50 | 10 | 2 | 46 | 700 | 43 | 690 | 60.5 |
| JKH-W | 32SP-1 | 1:4 | 50*32 | 1 | 2 | 19 | 180 | 16 | 150 | 17.6 |
| JKH-W | 40SP-1 | 1:4 | 50*40 | 1 | 2 | 17 | 190 | 16 | 160 | 19.2 |
| JKH-W | 32SP-2 | 1:4 | 50*40 | 2 | 2 | 26 | 260 | 23 | 240 | 21.6 |
| JKH-W | 40SP-3 | 1:4 | 50*40 | 3 | 2 | 28 | 330 | 25 | 320 | 24.6 |
| JKH-W | 50SP-5 | 1:4 | 50*50 | 5 | 2 | 28.5 | 540 | 30 | 500 | 35.7 |
| JKH-W | 50SP-7.5 | 1:4 | 50*50 | 7.5 | 2 | 41 | 620 | 38 | 580 | 55.8 |
| JKH-W | 50SP-10 | 1:4 | 50*50 | 10 | 2 | 45 | 680 | 43 | 650 | 60.5 |
Vertical pump -JKH series Features:
1. JKH series vertical pumps are manufactured from higher grade raw material and can be define to FRPP,PVDF for customer selection;The pump power range from 0.75kw to 7.5kw;
2. There are more type designed base shape of choice to your needs,for example square,circle,groove extemal,standard type,special customized;The weight of the pump is lighter,more acid and alkali resistant,and better meet the needs of different industries;
3.Vertical acid and alkaline resistant pump:JKH series widely used in chemical or water recirculation,Fame scrubbers/waste treatment,PCB plating solutions,Wet processing,cleaning solutios,Deliver acid;
4.Airless vertical pumps;
5.Vertical pumps can run-dry without damage to vapor seal;
6.Beside,extra vapor seal can also stop the acid vapor to reach the bearing;
7.The seal plate made from high purity aluminum oxide ,excellent in wear resistanting ,hrat resistanting and chemicals resisting;
8.The motor shaft is designed and install from internally (no extension, no joint) to ensure stability and better performance as well to enable the motor to have longer lifespan;
9.It is designed to inside tank ;however ,the installation instruction should be followed and can be fitted together with filter system;
10.For corrosive environment, it is recommended to use Titanium bolt and nuts and Epoxy paint on motor body to prolong motor lifespan;different brands motor of choice to your needs,for example:QUCHI,TECO and ABB;
11.Max Operating Temperature: FRPP 75℃; PVDF:100℃;
12.JK has been certified with ISO9001:2015,CE certification,Production&sales intellectual property management system certification;
13.1 year warranty;
